CAMDEN Lazerpoint RF RX-90 User Manual

Adjust POT1 clockwise until the LED starts to flash. The RX-90
is in latching mode at this point. To remove latching mode,
turn POT 1 counter clockwise until the LED is solid again.
Note: Latching mode disables delayed mode. Transmitter
programmed as delayed mode will work as latching mode
transmitter.
Step 3
Deleting Transmitters
Delay Mode Transmitters
Set SW1 to ON.
Pressing and holding PB1 for 8 seconds will delete all
transmitters delay mode. The LED will flash rapidly for 4
seconds to indicate erasure of the codes.
No Delay Mode Transmitters
Set SW1 to OFF.
Pressing and holding PB1 for 8 seconds will delete all
transmitters no delay mode. The LED will flash rapidly for
4 seconds to indicate erasure of the codes.
Note that individual removal of specific codes is not possible
at this time.
Section 5
Technical Data
Model RX-90 Receiver
Size 2 5/8”H x 1 1/2”W x 13/16”D
(67mm x 38mm x 21mm)
Mounting 2 # 4 screws at 3” centers,
or Velcro (supplied)
Enclosure Clear plastic case
Operating Voltage 12 / 24 Volts, AC / DC
Current Draw 23 mA nominal @ 24 VAC
43 mA maximum @ 24 VAC
Response Time 30 – 200 ms
Memory Delay & No Delay 40 transmitters total
LED’s Indicate: relay status;
learn mode; erase mode &
potentiometer position
Output 1 x SPDT Relay contact
Rating 3 amps @ 30 VDC
Operating Time 1 – 30 seconds
Delay Time 1-15 seconds
Lazerpoint™ RF RX-90 Advanced Single Relay Receiver Installation Instructions
Page 3 of 7
Electrical Life 1 x 10
5
minimum
Temperature Rating -40 to 185°F (-40 to +85°C)
Certifications - FCC Part 15 Compliant
- Canada RSS CNR210:1078
1032 061A
- Meets: IEC60601-1-2:2007
- Patent Pending
Section 6
Warranty
Camden Door Controls guarantees the Lazerpoint RF to be
free from manufacturing defects for 3 years from date of
sale. If during the first 3 years a Lazerpoint RF component
fails to perform correctly, it may be returned to our factory
where it will be repaired or replaced (at our discretion)
without charge. Except as stated herein, Camden extends
no warranties expressed or implied regarding function,
performance or service.
NOTE: Batteries are exempt from this warranty!
