Daughterboard
Model
Optional
Frequency
Antenna
Colour
RX-DBB 300 MHz Blue
RX-DBO 318 MHz Orange
RX-DBR 390 MHz Red
RX-DBW 433 MHz White
Step 6
Using CM-RFCT Cable tool
Since the LED’s may be difficult to see once the RX-91 is
installed, a 33” long plug-in cable tool is available.
The CM-RFCT Cable Tool plugs into the opening on the
side of the receiver, and allows the installer to view LED’s
mounted on the free end. Pairs of LED’s mounted on both
sides of the cable increase visibility.
Display status is dependant on Dip switch 4 setting. Turn
OFF to view relay status, and turn ON to view the Signal
Strength.
When installation is complete, simply unplug the cable tool,
coil and save for another job.
Section 4
Technical Data
Model TX-9 Transmitter
Frequency: Operates in the 902 – 928
MHz ISM Band
Codes 1 million unique (20 bit) codes
Size 2 ¼” L x 5/8” W x 3/8” H
Mounting Double sided foam tape
Switch Connection 2 x 10” leads with ¼” quick
disconnect terminations
Built-in Piezo sounder Used for Low Battery status,
Battery Gauge™, and Stuck
Switch indicator.
Power 2 x AAA alkaline batteries
Battery life Minimum 500,000 operations
Range Over 500 ft (open area)
Temperature rating -40 to 185 F (-40 to +85 C)
Model RX-91 Receiver
Size 3 ½” L x 2” W x 1” H
Mounting 2 # 8 screws at 4” centers,
or Velcro (supplied)
Enclosure Clear plastic case
Operating voltage 12 / 24 Volts, AC / DC
Current Draw 23 mA nominal @ 24 VAC
63 mA maximum @ 24 VAC
+ 5 mA per RF module
Response time 30 – 200 ms
Lazerpoint™ RF RX-91 Basic Receiver Installation Instructions
Page 3 of 7
Memory 40 transmitters
LED’s Indicate: relay status; signal
strength; learn mode;
erase mode &
potentiometer position
Output 1 x SPDT relays
Relay contact rating 3 amps @ 30 VDC
Time Delay 1 – 30 seconds
Electrical Life 1 x 10
5
minimum
Temperature rating -40 to 185 F
(-40 to +85 C)
Certifications ·FCC Part 15 Compliant
·Canada RSS CNR210:1078
1032 061A
·Meets: IEC60601-1-2:2007
Patent Pending
Accessories:
Plug-in daughterboard’s extend capability with other
frequencies. Refer to the following chart:
CM-RFCT – A 33” long cable-tool for high visibility of
relay status and signal strength
Section 5
Warranty
Camden Door Controls guarantees the Lazerpoint RF
(TX-9, RX-91,or RX-92 models) to be free from manufacturing
defects for 3 years from date of sale.If during the first
3 years a Lazerpoint RF component fails to perform correctly,
it may be returned to our factory where it will be repaired
or replaced (at our discretion) without charge. Except as
stated herein, Camden extends no warranties expressed
or implied regarding function, performance or service.
NOTE: Batteries are exempt from this warranty!
