Page 4 - Manual FA01734-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
DESCRIPTION
Gearmotor
The gearmotor is designed and manufactured by Came S.p.A. and complies with the current safety standards laws.
The case, is partly made of cast aluminium, holds a working electromechanical, irreversible gearmotor, and partly made of ABS plastic
coating to hold the electronic connection terminals.
The CBX series comes in several versions depending on the intended use; whether it’s for residential, apartment block or industrial
applications, with mechanical or encoder based endstops (see paragraph 2.3 Contexts of application).
The complete range:
230V Gearmotor with mechanical gearmotor and control panels
001C-BX / 001C-BXK - 230V A.C. Gearmotor with mechanical endstop
002 ZC3 / 002 ZM3E - Control Panel
002 ZC3C / 002 ZM3EC - Control panel with safety locking of command buttons
230 V Gearmotor with encoder and control panels
001C-BXE / 001C-BXEK - 230V A.C. Gearmotor with encoder
002 ZCX10 – Control panel
002 ZCX10C – Control panel with safety locking of command buttons
230V/400V tri-phase Gearmotor with mechanical endstops and control panels
001C-BXT - 230V/400V A.C. tri-phase gearmotor with mechanical endstop
002 ZT6 – Control panel
002 ZT6C - Control panel with safety locking of command buttons
230V/400V tri-phase Gearmotor with encoder and control panel
001C-BXET - 230V/400V A.C. Gearmotor with encoder
002 ZT5 – Control Panel
002 ZT5C - Control panel with safety locking of command buttons
24V Gearmotor with encoder and control panels
001C-BXE24 - 24V D.C. Gearmotor with encoder
002 ZL80 – Control panel
002 ZL80C - Control panel with safety locking of command buttons
002LBD2 – Card for connecting two (12V - 1.2Ah) emergency batteries
The CBX series may come with some of the following accessories, depending on the type of installations (i.e. sectional, folding or sliding):
001 CMS – Release handle with customised key and reset cord (L = 7 m);
009 CCT – Simple 1/2” chain for large sliding or folding doors;
009 CGIU – Joint for 1/2” chain;
821XC-0150 – Manual winch for large sectional doors;
001 C002 – Pendulum release system;
001 C003 - Chain tension reset system and brackets for large sliding doors;
001 C004 – Chain tension reset system and brackets for large folding doors;
001 C005 – Chain transmission system for large sectional doors with heights greater than 5.5 m;
001 C006 – Package with two brackets for large sectional doors (specifi c for direct coupling applications with Ø 1 spring loaded shafts”);
001 C007/8 – Adaptors for sectional doors with Ø25 mm (C007), or Ø40 mm (C008) shafts;
001 C009 – Bracket for large sectional doors (specifi c for direct coupling applications with Ø 1 spring loaded shafts”);
001 C011 - Chain transmission mechanism for o -axis applications with a transmission ratio of 1:1
Make sure that the command and safety equipment and accessories are CAME originals; this ensures easy installation and system’s
maintenance.
