Description of parts
ACCESSORIES
① 821XC-0150 - Winch
② C002 – Pendulum release system
③ C003 - Chain tension reset system and brackets for large sliding doors
④ C004 - Chain tension reset system and brackets for large folding doors
⑤ C-005 / C011 - Chain transmission system for large sectional doors
⑥ C006 – Perforated brackets for motors on large sectional doors
⑦ C007/8 – Adaptors for large sectional doors
⑧ C009 – Bracket for motor support on large sectional doors
⑨ CMS – Release handle with key
⑩ CCT - Simple 1/2” chain
⑪ CGIU - 1/2” chain coupling
GEARMOTOR ASSEMBLY
① Motoriduttore
② Maniglia di sblocco
③ Calotta inferiore
④ Coperchio di protezione
