CAME FLUO-SL - Main Settings Menu (Continued)

FA00150-EN v.7 - 06/2017
29
CAME S.p.A.
Display
Description
Factory settings
LEAF
DOOR WEIGHT
Setting the weight of the door and the friction. Choose between the following values:
NO = very light door / no friction
MIN = light door / little friction
MED = middleweight / average friction
MAX = heavy door / a lot of friction
HEVY = automation HEAVY version, for heavy doors
MED
RAMP
ACCELERATION
TIME
Set the acceleration time. Choose between the minimum and maximum values:
minimum value = 100 ms (maximum acceleration)
maximum value = 2000 ms (minimum acceleration)
600
BTMD
BATTERY
MODE
Setting operation of battery power device, in absence of electricity. Choose between the following
values:
NO = battery not connected
EMER = emergency open
EMERGENCY - Automatic setting for Emergency automation.
CONT = continuation of normal operation of the door, with last cycle of opening
Note: the number of operations with battery, depends on the efficiency of the battery, the weight of
the doors and the present friction.
UNLK = the locking device is released and the door remains stationary.
NO
13.2 MEMORY MANAGEMENT MENU
Using the buttons ↑ and ↓ select MEM, press ENTER to select and adjust the following memory management menu.
Display
Description
Factory settings
FSET
FACTORY
SETTINGS
Restore all settings to factory defaults. Choose between the following values:
NO = no restore.
YES = restore to factory settings.
NO
FW
FIRMWARE
UPGRADE
Programming procedure of electronic control.
Insert the micro SD memory in the electronic control.
From this menu, choose the firmware version you want.
Press ENTER until it starts the programming procedure that lasts about 30 seconds (or about 2
minutes for EMERGENCY automations), at the end the display shows "SAVE".
After the procedure, remove the micro SD memory from the electronic control and store it for future
use.
Note: in the case of programming error or missing firmware (W100, W104), proceed as follows:
disconnect the power supply, insert the micro SD memory, give power supply, the programming
procedure starts automatically, or choose the firmware from this menu.
- - - -
SIN
SETTING
INPUT
You can upload the menu settings used in another automation, already stored in the micro SD
memory.
Choose between the following values:
NO = no upload
YES = upload the menu settings from the micro SD memory
NO
SOUT
SETTING
OUTPUT
You can save the menu settings of automation in use, in the micro SD memory. Choose between the
following values:
NO = no save
YES = save the menu settings of automation in the micro SD memory
NO
