OPERATING INSTRUCTIONS:
AUTO MODE
Program 02 - 14 will follow in sequence. The frequency is adjustable from 01 - 99 (FQN:01 - 99).
SLAVE MODE
The unit in Slave Mode will follow the unit in Master Mode (any other mode except DMX Mode and Slave Mode).
Connect Master an Slave units by using DMX cables.
SOUND MODE
The unit in Sound Mode will follow beat of the music thanks to the built in microphone. Adjust the
sensitivity of the microphone by changing value (SENS:00 - 31). The frequency of alternating programs is
adjustable from 01 - 99 (FQN:01 - 99).
P10 FLOW 5
7 colour chasing from 2 sides to middle
Speed & Flash interval adjustable
P11 FLOW 6
7 colour from middle to 2 sides
Speed & Flash interval adjustable
P12 FLOW 7
7 colour chasing mode
Speed & Flash interval adjustable
P13 FLOW 8
2 colour chasing in 1 way
Speed & Flash interval adjustable
Blackout & 7 colours
P14 FLOW 9
2 colour chasing in 2 way
Speed & Flash interval adjustable
Blackout & 7 colours
