CAMPAGNOLO Ekar RD21 - Page 5

REPLACING THE JOCKEY CAGE - Rev. 01/ 06-2021 CAMPAGNOLO COMPONENTS - TECHNICAL MANUAL
5
5) Remove the jockey cage fixing nut (Fig.6
/ Fig.7).
6) Use a T15 Torx wrench to remove the
nut on the jockey cage side, acting on the
clutch shaft (Fig.8 / Fig.9).
7) Remove the jockey cage and the sealing
ring (Fig. 10).
Fig.6 Fig.7
8 mm
Fig.8 Fig.9
T15
Fig.10
