Page #11 background image
Engine Oil Type SAE 10W-30
SAE 30W (Above 60˚ F)
Engine Oil Capacity
Briggs and Stratton engines 20 fl. oz.
Honda engines 18 fl. oz.
Robin engines 20 fl. oz.
Engine Fuel Capacity
Briggs and Stratton engines 0.75 gal
Honda engines 0.46 gal
Robin engines 0.95 gal
Pump Oil Type
Horizontal axial pumps Special. See Parts List.
Pump Oil Capacity
Horizontal axial pumps 4.5 fl. oz.
Pump Detergent Suction
Water to detergent ratio 10 to 1 (10% detergent)
Water Supply Requirements
Minimum inlet pressure 20 psi
Maximum inlet pressure 100 psi
Maximum inlet temperature 100˚ F
Minimum inlet flow rate 5 gpm
Inlet garden hose size 5/8” I.D.
Maximum inlet garden
hose length 50 ft
11
Daily
After first 5 hours of
operation
Every 25 hours of
operation
Every 50 hours of
operation
Each 100 hours of
operation or every 3
months
• Check water inlet screen and filter.
• Check engine oil levels. Fill as necessary.
• Check gasoline level. Fill as necessary.
• Change engine break-in oil. Use SAE30 or 10W-
30 detergent oil.
• Change oil if operating under heavy load or
high ambient temperature.
• Remove and clean foam pre-cleaner or foam air
filter (if applicable). Wash with water and mild
detergent. Dry thoroughly. Rub with oil and
squeeze to distribute oil.
• Change oil.
• Replace spark plug.
• Clean or replace paper air cleaner cartridge. Tap
gently to remove dirt.
• Change engine oil.
Maintenance Schedule Action needed
Maintenance Schedule
Horizontal Oriented Pressure Washers
Technical and Consumer Information
www.chpower.com
CHECKING PUMP OIL AND PUMP OIL
CHANGING
NOTE: The oil in the pump is a special
synthetic type and must only be
replaced by the exact same type. See
the pump parts lists for the type of oil
to order.
Some pumps have an oil sight glass to
check the pump oil level. The oil level
should be at about the middle of the
sight glass. It may be difficult to see the
oil, so tilting the unit some may help to
find the level line of the oil.
If the pump does not have a sight glass,
then the oil level cannot be checked.
Normally, it is not necessary to change
the oil in the pump.
If there is a noticeable amount of oil
that is leaking from the pump, then the
oil seals may be worn or damaged and
the unit should be taken to an autho-
rized Campbell Hausfeld Service Center
for repair.
Maintenance (Continued)
