Installation of aesthetic panel
【Figure
4a】
2 Install the hook on the aesthetic wooden panel and put the hook into the slot of the outer door of
dishwasher(see figure 4a). After positioning of the panel , fix the panel onto the outer door by
screws and bolts(See figure 4b) .
Installation of aesthetic
wooden panel
【Figure4b】
.takeawaythefour
short screws
. pin up the four long
screws
1
2
