165 HIM Series
Softener Operation Manual
Note:
1. Read all instructions carefully before operation.
2. Avoid pinched o-rings during installation by applying
(provided with install kit) NSF certified lubricant to all seals.
Rev 8, December 28 2011

Questions and Answers

  • Z
    zthompsonAug 14, 2025
    Why is the water from my Canature CAN165HIM-100 Water Dispenser hard?
    • A
      Ashley HornAug 14, 2025
      If the water from your Canature Water Dispenser is hard, several factors could be responsible: * The by-pass valve might be open; in that case, close the by-pass valve. * The unit might be out of salt; add salt to the tank. * The injector or screen could be plugged; clean these parts. * There might be a blocked water flow to the brine tank; check the brine tank refill rate. * Hard water might be present in the hot water tank, which requires repeated flushing. * A leak could exist between the valve and the central tube; inspect the central tube for cracks or o-ring damage and replace any faulty parts. * There may be an internal valve leak, requiring replacement of the valve seals, spacer, and piston assembly.
  • K
    Kurt KimAug 17, 2025
    How to fix low water pressure in Canature Water Dispenser?
    • K
      Kevin ChandlerAug 17, 2025
      If you're experiencing low water pressure with your Canature Water Dispenser, the issue might stem from: * Iron or scale buildup in the line feeding the unit. In this case, you should clean the pipes. * Iron buildup inside the valve or tank. To resolve this, clean the control and add resin cleaner to clean the bed, also increase regeneration frequency. * The inlet of the control being plugged by foreign material. If this is the case, remove the piston and clean the control valve.
  • Z
    Zachary LarsenAug 21, 2025
    What to do if Canature CAN165HIM-100 fails to start regeneration cycle?
    • C
      Carla JohnsonAug 21, 2025
      If your Canature Water Dispenser fails to start a regeneration cycle, consider these potential causes: * **No power supply:** Check the electrical service and fuse. * **Defective circuit board:** Replace any faulty parts. * **Power failure:** Reset the time of day.
  • A
    alexanderwilliamAug 25, 2025
    What causes too much water in brine tank of Canature CAN165HIM-100 Water Dispenser?
    • S
      Shannon PetersAug 26, 2025
      If there's too much water in the brine tank of your Canature Water Dispenser, it could be due to: * A plugged injector or screen. Cleaning these parts may resolve the issue. * The valve not regenerating, which may require replacing the circuit board, motor, or control. * Foreign material in the brine valve. Cleaning the parts is recommended.
  • M
    Marissa WalterAug 28, 2025
    How to stop continuous flow to drain in Canature CAN165HIM-100 Water Dispenser?
    • T
      tjohnsonAug 28, 2025
      If water is continuously flowing to the drain in your Canature Water Dispenser, consider these possibilities: * Incorrect valve settings. Ensure that you check and correct the valve settings. * Foreign material in the control valve. Clean the control to remove any obstructions. * An internal leak. If this is the case, replace the seals, spacers, and piston assembly.
  • C
    Christina ChapmanAug 31, 2025
    Why Canature Water Dispenser is not drawing brine?
    • B
      Brian ThomasAug 31, 2025
      If your Canature Water Dispenser isn't drawing brine, here are a few things to check: * The drain line flow control could be plugged. Clean the parts. * The injector or screen might be plugged. Clean these parts as well. * The inlet pressure may be too low. Increase the pressure to 25 PSI. * There could be an internal valve leak. In this case, replace the seals, spacers, and piston assembly.
  • B
    brad78Sep 3, 2025
    Why is there resin in drain line of Canature Water Dispenser?
    • F
      felicia90Sep 3, 2025
      If you find resin in the drain line of your Canature Water Dispenser, the causes could be: * Air in the water system. Check the well system for proper air eliminator control. * Incorrect drain line flow control (DLFC) button. Check for the proper flow rate.
  • C
    Christine LambertSep 7, 2025
    What causes high salt use in Canature Water Dispenser?
    • C
      christophermichaelSep 7, 2025
      If salt use is high in your Canature Water Dispenser, it could be that the refill time is too high. Check the refill time setting.
  • A
    Alexis MontoyaSep 10, 2025
    What to do if valve continuously cycles in Canature CAN165HIM-100?
    • R
      ramireztimothySep 10, 2025
      If the valve of your Canature Water Dispenser is continuously cycling, it may be due to a defective position sensor PCB. If that's the case, replace the faulty parts.

Summary

Water Softener Gallon Setting Chart

Specifications

System Initialization

Initializes the control screen with time and default gallon setting upon power-up.

Programming

Enter and Modify Settings

Guide to entering programming mode, selecting, and changing parameter values.

Program Options

Manual Regeneration

Instructions for initiating manual regeneration, both delayed and immediate cycles.

General Valve Installation

Start-up Instructions

Power Failure Operation

Details how the valve retains settings and resumes operation after a power interruption.

System Configuration

Injector and Drain Line Flow Control

Details specific valve configurations for injector and flow control settings.

Automatic Bypass Operation

Explains how the system bypasses hard water during regeneration cycles.

Safety Features and Sounds

Describes the brine tank safety float and expected operational sounds.

Manual Bypass

Maintenance

Salt Addition and Bridging

Guidance on maintaining salt levels and troubleshooting salt bridging issues.

Softener Care and Cleaning

Recommendations for cleaning and protecting the water softener unit.

Injector Assembly Cleaning

Resin Cleaner Usage

Power Head Exploded View

Power Head Parts List

Control Valve Exploded View

Control Valve Parts List

Trouble Shooting

Brine Tank Feeder Assembly

Manufacturers Warranty

Canature CAN165HIM-100 Specifications

General IconGeneral
BrandCanature
ModelCAN165HIM-100
CategoryWater Dispenser
LanguageEnglish
