Contact Rating
Make current Max. 30A & carry for 3S
Carry capacity 8A continuous : Relay 1
4A continuous : Relay 2, 3, 4
Rated voltage 250V AC/30V DC
Breaking Characteristics
Breaking capacity AC 1500VA resistive
1500VA inductive (PF=0.5)
220V AC, 5A(cosØ<=0.6)
Breaking capacity DC 135V DC, 0.3A (L/R=30ms)
250V DC, 50W resistive or
25W inductive (L/R=40ms)
Durability
Loaded contact 10,000 operation minimum
Trip Contact Rating
Rated Data Rated Current Ip :1A or 5A
Rated Frequency Fn : 50 Hz/60Hz
Drop out to pickup ratio >96%
Power consumption At Ip = 1A 0.2 VA
in current circuit At Ip = 5A 0.4 VA
Thermal withstand capability Dynamic current withstand
in current circuit (Half wave) : 250 x Ip
for 1 Sec : 100 x Ip
for 10 Sec : 30 x Ip
continuously : 4 x Ip
Measuring Input
Over-voltage category : II, Insulation voltage : 300V, Pollution Degree : 2, IP 54 from Front
09
