Replacement and maintenance
Information
The
power of
bulb
must not
be more
than
1W .
18
Replacing
lamp
16
12V 1WX2Max
1.Disconnect the electrical plug.
2.Use the“ ”type screwdriver to remove the damaged lamp from lamp hole.
3.Disconnect the connectors between damaged lamp and lamp wire.
4.Connect the connectors between new lamp and lamp wire. Put the lamp click
into place of lamp hole.
Warning: Lamp replacement must be done by qualified after-sales service maintenance
personnel.
Only self shielded lamps can be used in order to prevent
undue hot parts, fire hazards and exposure to UV
radiation.
If the supply cord is damaged, it must be replaced by the manufacturer
,
its service agent or similarly qualified persons in order to avoid a hazard
17
Required min. distance to surfaces (such as lids, oven
cloth or the like) in order to prevent hot parts and fire
hazards.
(- - - to be "0 45 m”)
