Canon EF 500mm f/4L IS II USM User Manual

ENG-14
10. Hood
The special hoods that come with all these
lenses cut out unwanted light and protect the
front of the lens from rain, snow, and dust.
To attach the hood, loosen the hood lock knob
by turning it counterclockwise. Fit the hood onto
the lens’s hood mount, and tighten the lock knob
to fix it in place. Use the same procedure, in
reverse, to remove the hood.
9. Infinity Compensation
Mark
For accurate focusing in MF on subjects at infinity
distance, look through the viewfinder while rotating
the focusing ring.
To compensate for shifting of the infinity focus
point that results from changes in temperature.
The infinity position at normal temperature is the
point at which the vertical line of the distance
scale L mark is aligned with the distance index.
Infinity compensation mark
Distance index
COPY

Canon EF 500mm f/4L IS II USM Specifications

General

Focal Length	500mm
Maximum Aperture	f/4
Minimum Aperture	f/32
Lens Mount	Canon EF
Image Stabilization	Yes
Autofocus	Yes
Minimum Focusing Distance	3.7m
Filter Size	52mm (Drop-in)
Weight	3190g
Optical Design	16 elements in 12 groups
Number of Diaphragm Blades	9
Format Compatibility	Full-Frame
Maximum Magnification	0.15x
Weather Sealing	Yes
Angle of View	5°
