COPYRIGHT © 1998 CANON INC. CANON PC400/420/430,FC200/220 REV.0 JAN.1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
3-12
CHAPTER 3 EXPOSURE SYSTEM
4) Remove the four screws (t, M4X8,
yellow; y, M3X6, white), and detach
the copyboard drive assembly u as
if to lift it.
Figure 3-303B
To Next Page
