Names of buttons and switches other than the
joystick are indicated within a
“button” frame
(for example ).
Components Guide
Left side view
Front view
Right side view
RESET button ( 84)
button ( 24)/
(print/share) button ( 63, 72)
DISP. (on-screen display) button
( 49, 60)/
BATT. INFO button ( 18)
USB terminal ( 67)
AV OUT terminal (yellow) ( 67)
MIC terminal (red) ( 50)
Speaker ( 38)
Strap mount ( 21)
ACCESS (memory access) indicator
( 32, 54)/
CHG (charge) indicator ( 19)
DC IN terminal ( 19)
Mini video light ( 44)
Stereo microphone
FUNC.
COPY
