Canon imageCLASS D661 - The Paper Path of the Automatic Document Feeder

3-5
The Paper Path of the Automatic Document Feeder
• When documents are set in the ADF, the scanning unit moves to the position shown in the figure above
and it is fixed there.
When a document is placed on the platen glass, the scanning unit moves to scan it.
NOTE
1
4
2
3
Scanning
unit
The machine scans documents
from the last page.
Document Handling
3
