1
2
3
LBP226dw
17"
(431 mm)
14 3/4"
(373 mm)
2 3/4"
(70 mm)
15 3/4"
(399 mm)
*
9 7/8"
(250 mm)
5 1/8"
(131 mm)
Cassette feeding
module (optional)
* The protruding portion is not included. The whole
length, if the portion included, is 15 3/4" (401 mm).
4
Installation of the Machine
Quick Setup
