Before starting the installation
• Remove all of the tape.
• Do not remove the sticker that covers the USB
port.
Sticker
Installation requirements
Provide a space of 4" (100 mm) or more around
the machine.
LBP228dw / LBP227dw
17"
(431 mm)
14 3/4"
(373 mm)
2 3/4"
(70 mm)
17 1/4"
(438 mm)
12 1/4"
(312 mm)
5 1/8"
(131 mm)
Cassette feeding
module (optional)
Toner cartridge (included with the machine)
3
Installation of the Machine
Installing the MachineItems Included with the Machine
Quick Setup
