Canon imagePROGRAF iPF760 Basic Guide

8
With the nozzles facing down and the metal contacts
toward the back, insert the Printhead into the Car-
riage. Carefully push the printhead firmly into the Car-
riage, ensuring that the nozzles and metal contacts
do not touch the carriage.
9
Pull the Printhead Fixer Cover down toward the front
to lock the Printhead in place.
10
Push the Printhead Fixer Lever toward the back of
the printer until it clicks.
11
Close the Top Cover.
Replacing the Printhead iPF760
Basic Guide
Maintenance and Consumables Printheads
32

Canon imagePROGRAF iPF760 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
