74 Video
2 Touch and hold [y] or [A] to adjust the audio recording level as
necessary.
As a guideline, adjust the audio recording level so that the audio level
meter will go to the right of the -12 dB mark only occasionally.
3Touch [a] to lock the audio recording level at the current level.
To display the audio level indicator
Usually, the audio level indicator will be displayed only after activating
the manual adjustment of the audio recording level. You can choose to
display it also when the audio level is adjusted automatically.
NOTES
• When the audio level meter reaches the red point (0 dB), the sound may
be distorted.
• If the audio level is too high and the sound gets distorted, activate the
microphone attenuator with the 7 8 [Microphone Attenuator] set-
ting.
• We recommend using headphones to check the sound level while
adjusting the audio recording level or when the microphone attenuator
is activated.
Using Headphones
Use headphones for playback or to check the audio level while record-
ing. The headphones are connected to the AV OUT/X terminal, which
is used for both the headphones and the audio/video output. Before
connecting the headphones, follow the procedure below to change the
function of the terminal from AV output to X (headphones) output.
* Headphones can be used also in mode but the function of the terminal can-
not be changed. Change the setting in advance in mode.
[FUNC.] 8 [c Mic. Level] 8 [z Automatic] 8
[Audio Level Indicator] 8 [a]
Operating modes:
*
