FIGURE &
KEY No.
PART NUMBER
RANK
QTY
DESCRIPTION
REMARKS
5- 1 QC2-4711-000 1 FRAME, PANEL
2 QM3-2238-000 1 PANEL BOARD ASS'Y
3 QC2-4629-000 1 COVER, PANEL BOARD
4 QC2-4724-000 1 COVER, LCD FRONT
5 QC2-4725-000 1 COVER, LCD TOP
6 QC2-4726-000 1 WINDOW, LCD
7 QK1-3926-000 1 CORE, RING
8 QC2-4867-000 2 HINGE, LCD
9 QC2-4868-000 2 SPRING, HINGE
10 QC2-4756-000 1 COVER, FUNCTION KEY
11 QC2-4718-000 1 WINDOW, POWER LED
12 QC2-4721-000 1 WINDOW, ERROR LED
13 QC2-4837-000 1 WINDOW, LED
14 QC2-4841-000 1 BASE JOG WHEEL
15 QC2-4848-000 1 JOINT, JOG WHEEL
16 QC2-4833-000 1 KEY, OK
17 QC2-4834-000 1 JOG WHEEL
18 QC2-4840-000 1 KEY, RING
19 QC2-4640-000 1 KEY, OPERATION L
20 QC2-4641-000 1 KEY, OPERATION R
21 QC2-4761-000 1 KEY, FUNCTION
To Next Page
