FIGURE &
KEY No.
PART NUMBER RANK QTY DESCRIPTION REMARKS
7- 1 QC1-9987-000 1 COVER, GAP W/O CDR PRINTING
2 QM3-2219-000 1 INNER COVER UNIT
3 QC2-0424-000 2 ARM, RELEASE
4 QM3-2240-000 1 IRDA BOARD ASS'Y
5 QM3-2239-000 1 CARD BOARD ASS'Y
6 QM3-2469-000 1 PICTBRIDGE HARNESS ASS'Y
7 QM3-2475-000 1 CARD GND HARNESS ASS'Y
8 QM3-2470-000 1 CARD HARNESS ASS'Y
B-14
