Canon MP970 - Page 82

FIGURE &
KEY No.
PART NUMBER RANK QTY DESCRIPTION REMARKS
14- 1 QC1-9941-000 1 CAM, SWING ARM LOCK
2 QL2-1450-000 1 PR LIFT SHAFT ASS'Y
3 QC1-6232-000 2 SPRING, TENSION
4 QM2-3890-000 1 PAPER GUIDE UNIT
5 QC1-9937-000 4 SPRING, TORSION
6 QM2-3886-010 1 PRESSURE ROLLER ASS'Y
7 QM3-1273-000 1 CARRIAGE LIFT SENSOR UNIT
8 QC2-4433-000 1 CARRIAGE LIFT GEAR BASE UNIT
9 QC2-1873-000 1 GEAR, INPUT CARRIAGE LIFT
10 QC1-6212-000 1 GEAR, IDLER CARRIAGE LIFT
11 QC2-0039-000 1 SPRING, TORSION
12 QC2-0038-000 1 GEAR, OUTPUT CARRIAGE LIFT
13 QC2-0052-000 1 SPRING, TENSION
14 QC2-0040-000 1 LEVER, SWING ARM LOCK
15 QM3-1274-000 1 PE SENSOR UNIT
16 QK1-3849-000 1 MOTOR, PAPER FEED
17 QC1-9939-000 1 BUSHING
18 QC2-4880-000 1 FILM, TIMING SLIT DISK
19 QC1-6230-000 1 BELT, PAPER FEED
20 QL2-1490-000 1 FEED ROLLER ASS'Y
21 QC1-6225-000 1 GEAR, EJECT
22 QM3-2464-000 1 TIMING SENSOR UNIT
B-28
