D.
SCREW & WASHER LIST
󲩷
FIGURE &
KEY No.
PART NUMBER RANK QTY DESCRIPTION REMARKS
S- 1 XB4-7300-809 SCREW, TAP, BINDING HEAD, M3X8
2 XB1-2300-605 SCREW, MACHINE, M3X6
3 XB4-7300-805 SCREW, TP, BH3X8
4 XB1-2300-405 SCREW, MACH.BH, M3X4
5 XA9-1752-000 SCREW, TAP, WASHER HEAD, M3X12
6 XB2-4300-605 SCREW, W/WASHER, M3X6
7 XA9-1754-000 SCREW, BIND, M2.6X4(RED)
8 XB1-2200-405 SCREW, M2X4
9 XB2-7300-605 SCREW, W/WASHER, M3X6
10 XB6-7300-605 SCREW, MACHINE, TP, M3X6
D-1
