F.
NUMERICAL INDEX
󲩷
PART NUMBER
FIGURE
&
KEY No.
DESCRIPTION
QA4-1117-000 1- 1 TRAY, CD SUB
QC1-6201-000 11- 2 SPRING, LEAF
QC1-6202-000 11- 11 SPRING, COIL
QC1-6212-000 14- 10 GEAR, IDLER CARRIAGE LIFT
QC1-6225-000 14- 21 GEAR, EJECT
QC1-6230-000 14- 19 BELT, PAPER FEED
QC1-6232-000 14- 3 SPRING, TENSION
QC1-6526-000 11- 1 FILM, TIMING SLIT STRIP
QC1-6573-000 6- 3 DAMPER, DOOR
QC1-6619-000 12- 3 SPRING, TENSION
QC1-9023-000 3- 1 EMBLEM
QC1-9024-000 3- 1 EMBLEM
QC1-9937-000 14- 5 SPRING, TORSION
QC1-9939-000 14- 17 BUSHING
QC1-9941-000 14- 1 CAM, SWING ARM LOCK
QC1-9987-000 7- 1 COVER, GAP
QC2-0030-000 13- 3 COVER, INK TUBE
QC2-0038-000 14- 12 GEAR, OUTPUT CARRIAGE LIFT
QC2-0039-000 14- 11 SPRING, TORSION
QC2-0040-000 14- 14 LEVER, SWING ARM LOCK
QC2-0052-000 14- 13 SPRING, TENSION
QC2-0080-000 11- 3 CLIP, SHAFT R
QC2-0083-000 11- 5 CLIP, SHAFT L
QC2-0085-000 13- 4 TUBE, INK JOINT
QC2-0089-000 13- 2 TUBE, INK
QC2-0414-000 11- 9 SHAFT, CARRIAGE
QC2-0424-000 7- 3
A
RM, RELEASE
QC2-1799-000 4- 3 SHEET, DOCUMENT PRESSURE PLATE
QC2-1873-000 14- 9 GEAR, INPUT CARRIAGE LIFT
QC2-4425-000 11- 7 CAM, CARRIAGE SHAFT L
QC2-4426-000 11- 4 CAM, CARRIAGE SHAFT R
QC2-4433-000 14- 8 CARRIAGE LIFT GEAR BASE UNIT
QC2-4629-000 5- 3 COVER, PANEL BOARD
QC2-4633-000 4- 6 COVER, FLAPPER
QC2-4634-000 4- 7 SPRING, TORSION
QC2-4635-000 4- 8 SPRING, TORSION
QC2-4636-000 1- 5 SHEET,PANEL
QC2-4637-000 4- 11 COVER, PANEL
QC2-4638-000 4- 11 COVER, PANEL
QC2-4640-000 5- 19 KEY, OPERATION L
QC2-4641-000 5- 20 KEY, OPERATION R
QC2-4652-000 4- 11 COVER, PANEL
QC2-4666-000 3- 5 DOOR, CARD
QC2-4667-000 3- 9 WINDOW,CARD LED
QC2-4703-000 4- 5 COVER, TOP
QC2-4705-000 4- 2 FRAME, DOCUMENT PRESSURE PLATE
QC2-4711-000 5- 1 FRAME, PANEL
QC2-4718-000 5- 11 WINDOW, POWER LED
QC2-4721-000 5- 12 WINDOW, ERROR LED
QC2-4724-000 5- 4 COVER, LCD FRONT
QC2-4725-000 5- 5 COVER, LCD TOP
QC2-4726-000 5- 6 WINDOW, LCD
QC2-4756-000 5- 10 COVER, FUNCTION KEY
QC2-4761-000 5- 21 KEY, FUNCTION
QC2-4833-000 5- 16 KEY, OK
QC2-4834-000 5- 17 JOG WHEEL
QC2-4837-000 5- 13 WINDOW, LED
QC2-4840-000 5- 18 KEY, RING
QC2-4841-000 5- 14 BASE JOG WHEEL
QC2-4848-000 5- 15 JOINT, JOG WHEEL
QC2-4867-000 5- 8 HINGE, LCD
QC2-4868-000 5- 9 SPRING, HINGE
QC2-4880-000 14- 18 FILM, TIMING SLIT DISK
QC2-4881-000 12- 4 FILM, TIMING SLIT DISK EJECT
PART NUMBER
FIGURE
&
KEY No.
DESCRIPTION
QC2-4888-000 12- 1
A
BSORBER, INK
QC2-4900-000 3- 1 EMBLEM
QC2-5978-000 10- 4 COVER, PAPER FEED GUIDE
QH2-2716-000 1- 4 CORD, POWER
QH2-2719-000 1- 4 CORD, POWER
QK1-0776-000 1- 4 CORD, POWER
QK1-1500-000 11- 6 MOTOR, CARRIAGE
QK1-3670-000 2- 1
A
C ADAPTER: 100V-240V 50/60Hz
QK1-3761-000 1- 4 CORD, POWER
QK1-3849-000 14- 16 MOTOR, PAPER FEED
QK1-3852-000 11- 12 CORE, RING
QK1-3926-000 5- 7 CORE, RING
QL2-0938-000 11- 10 IDLER PULLEY ASS'Y
QL2-1449-000 1- 2 CDR TRAY ASS'Y
QL2-1450-000 14- 2 PR LIFT SHAFT ASS'Y
QL2-1490-000 14- 20 FEED ROLLER ASS'Y
QM2-3886-010 14- 6 PRESSURE ROLLER ASS'Y
QM2-3890-000 14- 4 PAPER GUIDE UNIT
QM3-0033-010 13- 1 PURGE UNIT
QM3-0259-000 10- 1 DC CONNECTOR ASS'Y
QM3-0296-000 10- 2 MOTOR MULTI HARNESS ASS'Y
QM3-1273-000 14- 7 CARRIAGE LIFT SENSOR UNIT
QM3-1274-000 14- 15 PE SENSOR UNIT
QM3-2210-000 6- 1 MAIN CASE UNIT
QM3-2211-000 6- 2 FRONT DOOR UNIT
QM3-2212-000 3- 8 SCANNER LOCK ARM UNIT
QM3-2213-000 3- 7 SIDE COVER R UNIT
QM3-2215-000 3- 6 SIDE COVER L UNIT
QM3-2216-000 3- 3 PAPER SUPPORT UNIT
QM3-2217-000 9- 2 BOTTOM CASE UNIT
QM3-2218-000 3- 4 CASSETTE UNIT
QM3-2219-000 7- 2 INNER COVER UNIT
QM3-2220-000 3- 2 SCANNER UNIT
QM3-2225-000 4- 1 DOCUMENT PRESSURE PLATE UNIT
QM3-2228-000 4- 9 HINGE UNIT
QM3-2230-000 10- 5 SHEET FEEDER UNIT
QM3-2231-000 11- 8 CARRIAGE UNIT
QM3-2233-000 4- 4 FILM GUIDE UNIT
QM3-2237-000 8- 1 LOGIC BOARD ASS'Y
QM3-2238-000 5- 2 PANEL BOARD ASS'Y
QM3-2239-000 7- 5 CARD BOARD ASS'Y
QM3-2240-000 7- 4 IRDA BOARD ASS'Y
QM3-2242-000 12- 2 PLATEN UNIT
QM3-2445-000 4- 10 PANEL MULTI HARNESS ASS'Y
QM3-2464-000 14- 22 TIMING SENSOR UNIT
QM3-2469-000 7- 6 PICTBRIDGE HARNESS ASS'Y
QM3-2470-000 7- 8 CARD HARNESS ASS'Y
QM3-2471-000 10- 3 ENCODER MULTI HARNESS ASS'Y
QM3-2475-000 7- 7 CARD GND HARNESS ASS'Y
QY5-0181-000 9- 1
A
BSORBER KIT
QY6-0062-010 1- 3 PRINT HEAD
QY9-0057-000 T- 1 LUBE, FLOIL KG107A, OIL
WT3-5156-000 1- 4 CORD, POWER
XA9-1752-000 S- 5 SCREW, TAP, WASHER HEAD, M3X12
XA9-1754-000 S- 7 SCREW, BIND, M2.6X4(RED)
XB1-2200-405 S- 8 SCREW, M2X4
XB1-2300-405 S- 4 SCREW, MACH.BH, M3X4
XB1-2300-605 S- 2 SCREW, MACHINE, M3X6
XB2-4300-605 S- 6 SCREW, W/WASHER, M3X6
XB2-7300-605 S- 9 SCREW, W/WASHER, M3X6
XB4-7300-605 S- 11 SCREW, BH, M3X6
XB4-7300-805 S- 3 SCREW, TP, BH3X8
XB4-7300-809 S- 1 SCREW, TAP, BINDING HEAD, M3X8
XB6-7300-605 S- 10 SCREW, MACHINE, TP, M3X6
F-1
