Canon XF105 User Manual

Optional Accessories
170
Battery Packs
When you need extra battery packs, select from the following: BP-925,
BP-955, BP-975, BP-950G, BP-970G.
When you use battery packs bearing the Intelligent System mark, the
camcorder will communicate with the battery and display the remaining
usage time (accurate to 1 minute). You can only use and charge these
battery packs with camcorders and chargers compatible with Intelligent
System.
Charging Times
Use the CA-930 Compact Power Adapter to charge battery packs. The charging times given in the following
table are approximate and vary according to charging conditions and initial charge of the battery pack.
Recording and Playback Times
Recording and playback times given in the following tables are approximate and vary according to recording
mode and charging, recording or playback conditions. The effective usage time of the battery pack may
decrease when recording in cold surroundings, when using the brighter screen settings, etc.
b
Use of genuine Canon accessories is recommended.
This product is designed to achieve excellent performance when used with genuine Canon accessories.
Canon shall not be liable for any damage to this product and/or accidents such as fire, etc., caused by the
malfunction of non-genuine Canon accessories (e.g., a leakage and/or explosion of a battery pack). Please
note that this warranty does not apply to repairs arising out of the malfunction of non-genuine Canon
accessories, although you may request such repairs on a chargeable basis.
BP-925 BP-955 BP-950G BP-970G BP-975
110 min. 200 min. 245 min. 350 min. 295 min.
Bit rate Usage time BP-925 BP-955 BP-950G BP-970G BP-975
50 Mbps Recording (maximum) Viewfinder 165 min. 345 min. 350 min. 490 min. 520 min.
LCD screen 165 min. 340 min. 345 min. 485 min. 510 min.
Recording (typical)* Viewfinder 105 min. 220 min. 220 min. 310 min. 320 min.
LCD screen 105 min. 215 min. 215 min. 305 min. 315 min.
Playback LCD screen 225 min. 460 min. 470 min. 655 min. 695 min.
35 Mbps Recording (maximum) Viewfinder 165 min. 345 min. 350 min. 490 min. 520 min.
LCD screen 165 min. 340 min. 345 min. 485 min. 510 min.
Recording (typical)* Viewfinder 105 min. 220 min. 220 min. 310 min. 320 min.
LCD screen 105 min. 215 min. 215 min. 305 min. 315 min.
Playback LCD screen 225 min. 465 min. 470 min. 675 min. 695 min.
25 Mbps Recording (maximum) Viewfinder 170 min. 355 min. 360 min. 505 min. 530 min.
LCD screen 170 min. 345 min. 355 min. 495 min. 525 min.
Recording (typical)* Viewfinder 105 min. 225 min. 225 min. 315 min. 325 min.
LCD screen 105 min. 220 min. 220 min. 310 min. 320 min.
Playback LCD screen 230 min. 475 min. 485 min. 680 min. 715 min.
BP-955 BP-975
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
