Canon XF105 User Manual

41
Recording Video
Recording in Full Auto Mode
Move the CAMERA switch to FULL AUTO to change the camcorder to
full auto mode. In full auto mode, the camcorder automatically sets the
iris, gain, shutter speed, and white balance. The camcorder will
continuously adjust the brightness and white balance automatically*. In
full auto mode, however, the autofocus will not be turned on.
* The light metering mode (0 58) will be set to [Standard], the AE level (0 58) will be
set to [±0] and the AGC limit (0 53) will be set to [Off/24 dB].
Locking Buttons
Moving the CAMERA switch to R will lock the following buttons: IRIS,
GAIN, SHUTTER, WB, S, AF/MF. Doing so will also lock the settings
of the corresponding functions. This is useful in preventing settings from
being changed due to inadvertently pressing one of the buttons.
About Clips
When the camcorder records a clip, it also assigns a 6-character clip
name consisting of a 2-letter prefix and 4 numerals (for example, “AA0001”). The numerals increase every
time a clip is recorded. You can set the initial clip name in advance using the [J Other Functions] [Clips]
[Title Prefix] and [Number Setting] settings. You cannot change the clip name after the clip is recorded.
The video file (stream) in a clip will be split approximately every 2 GB for clips with a long recording time. Even
in such case, playback will be continuous.
NOTES
• If you are recording with two CF cards and the CF card you are using becomes full while recording, the clip
will continue uninterrupted on the other CF card when relay recording (0 38) is activated. In such case,
the recording will be recorded as separate clips.
• If you record using the custom picture and metadata settings, those settings will be recorded with the clip.
For more details, refer to Custom Picture Settings (0 96) and Using Metadata (0 79).
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
