Your gas appliance must be installed on a flat, stable surface, away from any
combustible materials or construction.
Your gas appliance comes assembled, ready for a gas connection.
1-Remove the appliance from container box and place it on any level, outdoor,
non-combustible surface.
NOTE: Do not place this appliance on grass or dirt area. This may prevent proper
safety venting.
2-Open the gas door and put the cylinder inside.
3-Unscrew the battery box as shown in Fig. 1 Insert the negative electrode side of
the battery into the bottom of battery box as shown in Fig. 2 Then screw the battery
box as shown in Fig. 3.
Note: If the battery of the pulse electronic igniter runs out of power, please replace
with new battery.
1-Check the pressure regulator and place the tank rack next to the fire table as
shown in Fig. 4.
2-Unscrew the locking device on tank rack per Fig. 5-1; place cylinder on the rack
and then tighten locking device as shown in Fig. 5-2 and Fig. 5-3.
3-Connect the regulator and the cylinder as shown in Fig.6. Make sure there is no
leakage or damage (please refer to “Leak Test” on page 9 and 10 damage checking
on page 5).
4- Disconnect the regulator and the cylinder as shown in Fig. 7.
8
LOCATION
SETUPGas Connection
8
of
11
