MODEL NO. 088-0342-8
ASSEMBLY
PART LIST
Left frame
-
4
Right frame
-
4
Pole - 4
Lower roof top connector - 1
Hook - 1
M6 x 20 Bolt - 28+ 2 spare
Short bar - 4
M6 Flat washer - 40+ 2 spare
M6x40 Screw -
Medium bar - 4
M6 Nut - 12+ 1 spare
Long bar - 4
Wrench - 1
Lower roof canopy - 1
Stake - 12
Touch-up paint - 1
Upper roof top connector - 1
Top pole - 4
Top roof canopy - 1
Mosquito net - 1
Plastic ring - 40
1A
1B
1C
2A
2B
AA
2C
BB
CC
2D
DD
2E
W
W
3A
GG
HH
3B
3C
3D
3E
3E1
Let us help you!
DO NOT RETURN YOUR PRODUCT TO THE STORE. CALL US FIRST!
1-888-670-6684
If you have questions regarding your product, require warranty
assistance, or have damaged or missing parts, please call our customer
service toll-free helpline. Contact us for assistance; we’re here to help.
CAUTION!
~ Proper placement of the gazebo is essential. Do not place the product
underneath electrical lines.
~ Keep children under close supervision while they are playing around this
product. This product contains small parts which can be swallowed by
children.
~ Keep fingers away from places where they can be pinched or trapped.
~ Do not attempt to assemble the gazebo if any part is missing.
IMPORTANT: Please read and understand this manual before any assembly. Before beginning
assembly of the product, make sure all parts are present. Compare parts with packaging
contents list. If any part is missing, or if you have any questions, contact the service centre at
1-888-670-6684 (toll-free).
Take all parts from the packaging box and position them on a clean floor. Remove all packing
materials and place them back into the box. Do not dispose of the packing materials until
assembly is complete. Read each step carefully before beginning any assembly and make sure
you understand each step.
Needed for assembly:
2 People
Screwdriver
Ladder
Hammer
12+ 2 spare
To Next Page
