Canvas 088-2075-2 User Manual

B
Model NO. 088-2075-2
ASSEMBLY
6
ASSEMBLY
7
Step 1
Requires H, I
(1) Open the side bases (H) and the middle bases (I) by turning
caps in a counter-clockwise direction.
(2) Pour sand or water into the side bases (H) and the middle
bases (I).
(3) Close the side bases (H) and the middle bases (I) by turning
caps clockwise.
Step 3
Requires A, B, C, F, G, AA, BB, CC, EE, FF, GG
(1) Attach the pedal (F) to the turn plate (G).
(2) Use M6x10 flat bolt (EE) and M6 hex wrench (FF) to secure
pedal (F).
(3) Attach the turn plate (G) to the brackets (A and B) using M10x25
bolts (AA) and flat washers (CC).
(4) Attach the base tube (C) to the turn plate (G) using M10x22
bolts (BB), flat washers (CC) and the M10 hex wrench (GG).
OPEN
CLOSE
H
Sand
Step 2
Requires A, B
Attach the upper bracket (B) onto the lower bracket (A).
B
A
GG
C
BB
CC
AA
G
F
EE
FF
