20
20
13
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
H Nut cap 20
I
J
Stake
8
K
Hex key
2
A M6x10 bolt 12
B M6x15 bolt 198
C M6x40 bolt
D M6x55 bolt 8
E 10mm nut with M6 threads 28
F Roof bolt 8
G Washer 20
Wrench
2
SKYLINE 10'X12' DOUBLE-TIER GAZEBO
