17SKYLINE 10'X12' DOUBLE-TIER GAZEBO
STEP 3
5
X2
4
B
5
A
4
5
4
NOTE:
Do not install bolts in the
two outer holes marked
with X’s.
A
X4
B
X4
5
X2
4
X2
NOTE:
Install all bolts by hand loosely
threaded BEFORE fully tightening
any bolts. Once all bolts are installed
loosely, then secure the bolts before
moving on to the next step.
X2
NOTE:
The beam ends have a plastic insert
for easier assembly. This part is
critical for a complete assembly of
your gazebo. If any of your beams
are missing this plastic insert please
contact us at 1-888-670-6684
