PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
21
Edge roof cap
(long & short side)
8
22 Main roof rafter hub 1
23 2nd tier rafter hub 1
25 Foot plate cover 4
24 2nd tier top cover 1
26 Foot plate 4
14
Left middle roof panel
(long & short side)
4
15
Right middle roof panel
(long & short side)
4
16
Left small roof panel
(long & short side)
4
17
Right small roof panel
(long & short side)
4
18
Short side center
roof panel
2
19
Long side center
roof edge cap
2
20
Short side center
roof edge cap
2
SKYLINE 10'X12' DOUBLE-TIER GAZEBO
