20
20
13
H Capuchon d’écrou 26
I
J
Piquets
8
K
Clé hexagonale
2
A Boulon M6x10 12
B Boulon M6x15 228
C Boulon M6x40
D Boulon M6x55 8
E Écrou de 10 mm avec filets M6 34
F Boulon de toit 8
G Rondelle 26
Clé
2
LISTE DU MATÉRIEL
ÉLÉMENT DESCRIPTION ILLUSTRATION QUANTITÉ
ABRI DE JARDIN SKYLINE À TOIT À DEUX NIVEAUX DE 12 X 14 PI
