PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
21
Long side center
roof panel
22
Short side center
roof edge cap
2
23
Long side center
roof edge cap
2
25 Main roof rafter hub 1
24
Edge roof cap
(long & short side)
8
26 2nd tier rafter hub 1
14
Roof top cover 2
4
15
Left roof panel
(long & short side)
4
16
Right roof panel
(long & short side)
4
17
Left middle roof panel
(long & short side)
4
18
Right middle roof panel
(long & short side)
4
4
4
2
19
Left small roof panel
(long & short side)
20
Right small roof panel
(long & short side)
SKYLINE 12'X14' DOUBLE-TIER GAZEBO
