Canvas CABANA User Manual

Model NO. 088-2075-2
ASSEMBLY
12
ASSEMBLY
13
Step 12
Requires J
Slowly turn the crank (J) in a counterclockwise direction to
close the umbrella.
Step 14
Tie the umbrella to the umbrella pole with the strap when
not in use, as shown below.
Step 13
Requires K
Press the button on the umbrella shade (K) and push down.
Operation
Attaching the crank
Attach the crank (J) to the handle as shown in figure 01.
Attach the crank (J) by aligning the tap with the hole on the crank
(J) until it snaps into place.
To detach the crank, the hex wrench (FF) is required to press the
tap to take the crank (J) out.
Attach the crank (J) without using the tap as shown in figure 02.
To detach the crank (J), just take the crank out.
Figure 1
Figure 2
