OPERATION
ATTACHING THE CRANK
1. Attach the crank (Q) to the handle as shown in Figure 1.
2. Attach the crank (Q) by aligning the tap with the hole on the crank
(Q) until it snaps into place.
DETACHING THE CRANK
1. To detach the crank, the hex wrench S4 (U) is required to press
the tap to take the crank (Q) out.
2. Attach the crank (Q) without using the tap as shown in Figure 2.
3. To detach the crank (Q), just take the crank out.
• Check all screws and nuts periodically for tightness, tightening them
again as required.
• Disassemble the umbrella in the reverse order of the assembly steps.
• Always disassemble the umbrella completely. A partially disassembled
umbrella is not stable enough to resist wind and bad weather, and
therefore can be damaged and/or cause damage.
• Clean the umbrella with mild soap and water. Rinse thoroughly, and wait
until the umbrella is completely dry before reassembling it.
CAUTION!
• Always use a mild soap, never detergent.
- Water should be cold to lukewarm, never more than 25 °C (77 °F).
• Steel components of garden accessories and furniture are treated with
rust-inhibiting paint. However, due to the nature of steel, surface oxidation (rusting)
will occur if this protective coating is scratched. This is a natural process. To minimize
this condition, it is recommended that care be taken when assembling and handling
the product, in order to prevent the paint from being scratched. Surface rust can be
removed easily using a very light application of common cooking oil. If surface
oxidation (rusting) occurs and no measures are taken to correct it, the oxidation may
start dripping onto the assembly surface, which may cause damaging stains that may
lt to remove.
Dimensions (DIA x H)
Product weight
137.79 x 108.27 in
350 x 275 cm
69.45 lb
31.5 kg
27
CLEANING & MAINTENANCE
SPECIFICATIONS
Figure 1
Figure 2
