that system at test pressures of 1/2 psi (3.5kPa).
supply piping system during any pressure testing of
the appliance must be disconnected from the gas
knob should spring back. If knob does not spring back,
replace valve assembly before using the griddle. Turn
knob to low position then turn back to OFF position.
Valve should turn smoothly.
Clean any blocked ports with a stiff wire such as an
CARE and GENERAL
MAINTENANCE
Wire brush the entire outer surface of the burner to
air into the burner tube and out the burner ports.
Important: To check valve, first push in knob and release,
Follow these instructions to clean the burner.
CLEANING THE BURNER ASSEMBLY
Remove griddle plate from assembly.
Turn gas OFF at the control knob.
Ensure all components have cooled.
Follow general cleaning guidelines as listed below.
remove food residue and dirt.
Customer Service for instructions and/or replacement.
If any cracks or holes are found, contact DDR
While wearing eye protection, use an air hose to force
Check each port to make sure air is coming out each
combustible materials, gasoline, and other flammable
If ignition does NOT occur in 5 seconds, turn the
Regularly inspect and clean burner tubes (as listed on
next page) for insects and insect nests. A clogged tube
can lead to a fire beneath the appliance.
Use long-handled barbecue utensils and oven
and smoke for paint. Do not apply a caustic griddle/
mitts to avoid burns and splatters.
Always keep appliance area clear and free from
or a concentrated oven cleaner on plastic parts.
dry. Do not use Citrisol, Abrasive cleaners, de-greasers
Turn control knob and gas source or tank OFF when
burner controls OFF, wait 5 minutes and repeat the
lighting procedure. If the burner does not ignite with
Keep ventilation openings in cylinder enclosure
Clean the griddle often, preferably after each use.
the valve open, gas will continue to flow out of the
burner and could accidentally ignite with risk of injury.
when in use. Do not obstruct the flow of
residue, pour warm water onto the hot griddle surface
Check and clean burner/venturi tubes for insects
pad on areas with graphics.
with a non-abrasive cloth.
To clean the griddle after each use, scrape gently with
Visually inspect burner flames (as noted on page 6).
oven cleaner to painted surfaces.
beneath the appliance. Please see "CLEANING
a metal spatula or scraper and wipe down the griddle
Do not mistake brown or black accumulation of grease
Keep portable/tabletop griddles away from
Never move griddle while in use or while hot.
walls, buildings, vehicles, or other structures
brushed finish to avoid damage. Do not use abrasive
Painted surfaces: Wash with mild detergent or
Plastic parts: Wash with warm soapy water and wipe
Damage to, and failure of, parts can result.
non-abrasive cleaner and warm soapy water. Wipe dry
abrasive plastic cleaning pad. Use only in direction of
Verify there are no obstructions to the flow of
combustion or ventilation air.
When the Capital brand griddle is not in use,
Assembly and Installation sections for details.
combustion or ventilation air. Refer to the
THE BURNER ASSEMBLY" on page 8.
ensure the control knob is in the OFF position.
free and clear of debris.
surface with a cloth or paper towel. For tough food
and let it boil the water off.
Baked-on grease deposits may require the use of an
and nests. A clogged tube can lead to a fire
TESTING FOR LP GAS LEAKS ON APPLIANCE
Never test appliance for a gas leak by using an open
flame. If you suspect a gas leak, grab a bottle of soapy
water and turn on the gas. Spray all the connections
until bubbles are formed. Tighten and recheck!
