15Instruction manual Wi158 & Wi159Please keep this instruction manual for future reference
INSTALLING THE FULL HEIGHT PLINTH GRILLE
Take out the full height plinth grille and the brackets from the accessories box. Fix the brackets
to the cabinet with screws provided and fix both sides of the grille to the brackets with the 2
supplied screws as shown in below diagram.
NOTE: To be installed with a
150mm plinth height.
If you wish to reduce your
plinth height, the smaller,
slot-on plinth grille (see page
14) should be used.
NOTE:
Full height plinth grille only
included with WI159.
