16 Instruction manual Wi158 & Wi159 Please keep this instruction manual for future reference
FITTING A KITCHEN PLINTH
This model is also supplied with a slot on plinth grille if the previous method/grille is not
preferred. A H75mm vent slot is required in the plinth to ensure air is able to ventilate correctly.
See diagram below.
