19Instruction manual Wi6135 & Wi6136Please keep this instruction manual for future reference
is model is recessed to fit
55mm
490mm
490mm
R25
55mm
R25
INSTALLING A SLOT-ON PLINTH GRILLE
This model is recessed to fit a kitchen plinth. A H55mm vent slot is required in the plinth to
ensure air can ventilate correctly. See the diagram below for the cut-out dimensions. This
appliance comes with a decorative plinth grille which slots onto the kitchen plinth.
NOTE: Failure to include the vent slot will invalidate the guarantee.
