ASSEMBLY & INSTALLATION INSTRUCTIONS continued

TILTING FUNCTION:

Pull the tilting device which is on the front-end of the base with reflector on it, the carrier can be easily tilted down for rear access.

SWING AWAY FUNCTION:

Loosen the locking knob and pull the wire lock pin out to swing the carrier to left or right and then tighten the locking knob

and insert the pin again to fix the carrier.
