Captron HeliCommand 3A 3D RIGID - Specification; Set Contents

Specication
40
Operating voltage: 4,8 ... 6 Volt (4 ... 5 NiXx)
Current drain: 55mA (at 5V)
Dimensions: 55 x 35 x 22,5 mm
Weight incl. cables: 33g
Temperature range: -5° ... +50°C; +23° ... +122°F
in ‚OFF‘ mode: -10° ... + 50° C; +14° ... +122°F
Swashplate linkage types: CCPM (separate servo functions, H1, single servo)
ECCPM: Tri-Link H3(120°), H3(140°), H3(90°), Four-Link H4(90°), 4(90+45°)
Max. allowed turn rates in „hor“- and „pos“-mode:
aileron and elevator: ≤ 200 °/s
yaw (also if external gyro used) : ≤ 400°/s
In EXTREM mode (HeliCommand Rigid only): unlimited turn rates!
Compatible with all current analog and digital servos, except for „narrow-
pulse“ (760 μs) servos.
Compatible with all usual RC systems, as for example:
Robbe-Futaba PPM / PCM 1024 / PCM G3 modulation / 2,4 GHz
Graupner/JR PPM 8, PPM 12, SPCM modulation
MPX PPM8, PPM 12 with UNI modulation
Any other transmitters with standard 1.5 ms neutral position.
Set contents
• HeliCommand main unit
• RC module (with cable distributor)
• Mounting bracket
• Self-adhesive double-sided foam tape, 2 sets of 2 strips each
• Cable ties
• Instruction manual
