Carefree FREEDOM FREESTYLE WM - User Manual

24 pages

Save Page as PDF

To Next Page

052573-301r8 Printed in USA July, 2017

ERVICE

ANUAL

FREEDOM FREESTYLE WM

12V

OTORIZED

ATERAL

WNING W

IRECT

ESPONSE

Read this manual before installing or servicing this product. Failure to follow the

instructions and safety precautions in this manual can result in personal injury and/or

cause the product to not operate properly.

Other manuals for Carefree FREEDOM FREESTYLE WM

Installation Manual12 pages

Questions and Answers

S
Stephanie ReidAug 1, 2025
What to do if my Carefree Automobile Accessories awning does not extend or retract?
- I
  irwincarlaAug 1, 2025
  If your Carefree Automobile Accessories awning isn't extending or retracting, start by checking the installation integrity using the wiring diagram to ensure all components and wiring are correctly installed and connected. Next, confirm that the vehicle battery or power source is providing 10V to 14V to the switch. You can also test the motor function by removing the outer end cap on the motor side, disconnecting the motor wires from the harness, and connecting the motor wires to a 12-14VDC power source. If the motor is defective, replace it; otherwise, continue testing. Ensure to repair any wiring issues and reconnect the wires. If the switches are defective, replace them; if the switches are good, the module is defective and needs replacement.
N
nwilliamsAug 15, 2025
Why lead rail does not close correctly on my Carefree FREEDOM FREESTYLE WM Automobile Accessories?
- C
  Christopher SimsAug 16, 2025
  If the lead rail on your Carefree Automobile Accessories isn't closing correctly, it could be due to an incorrect pitch setting; correct the pitch so the arms are even. Alternatively, try overextending the awning until the fabric rolls under the roller tube using the close position of the switch. Another possible cause is the lead rail connectors being set too far or too close from the end of the lead rail. If they are too far, loosen the screw and slide the connector toward the end of the lead rail. If they are too close, loosen the screw and slide the connector away from the end of the lead rail.
