easy compact parameter sets (EY)
Par. Description S models (normal temperature)
EY=1 EY=2 EY=3 EY=4
/4 select probe displayed 1111
/5 select °C/°F 0000
rd control di erential 3.0 3.0 5.0 2.0
r1 minimum set point value -10.0 -15.0 -20.0 -30.0
r2 maximum set point value 15.0 20.0 20.0 40.0
r3 select direct/reverse operation 1 0 2 0
c1 minimum time between consecutive compressor starts 3 5 0 6
c2 minimum compressor o time 2 4 0 4
d0 type of defrost 2204
dI interval between defrosts 6 10 6 12
dt end defrost temperature set point 5.0 5.0 5.0 5.0
dP maximum defrost duration 40 40 40 40
d6 freeze control temperature display during defrost 1 1 1 1
dC time base 0000
A0 alarm and fan temperature di erential 2.0 2.0 2.0 2.0
AL absolute temperature or deviation for low temperature alarm 20.0 25.0 20.0 20.0
AH absolute temperature or deviation for high temperature alarm 20.0 25.0 20.0 20.0
Ad temperature alarm delay 60 70 60 60
Table 5.g
Key:
EY= normal temperature
1
no defrost
2
defrost by time
3
heating output (reverse)
4
defrost with temp. control (d0= 4)
easy split parameter sets (EZY)
Par. Description models S-X (normal temperature) models Y-C (low temperature)
EZY=1 EZY=2 EZY=3 EZY=4 EZY=1 EZY=2 EZY=3 EZY=4
/4 select probe displayed 1 1 1 1 ----
/5 select °C/°F 0 0 0 0 ----
rd control di erential 3.0 3.0 5.0 2.0 3.0 4.0 5.0 2.0
r1 minimum set point value -10.0 -15.0 -20.0 -30.0 -30.0 -30.0 -30.0 -30.0
r2 maximum set point value 15.0 20.0 20.0 40.0 20.0 20.0 30.0 40.0
r3 select direct/reverse operation 1 0 2 0
r4 night-time set point delta - - - - 5.0 5.0 2.0 4.0
c1 minimum time between consecutive compressor
starts
35064536
c2 minimum compressor o time 2 4 0 42305
d0 type of defrost 2 2 0 41234
dl interval between defrosts 6 10 6 12 5 7 10 12
dt end defrost temperature set point/defrost temperature
threshold with temp. control
5.0 5.0 5.0 5.0 5.0 5.0 5.0 4.0
dP maximum defrost duration 40 40 40 40 20 40 10 50
d6 freeze control temperature display during defrost 1 1 1 1 ----
dC time base 0 0 0 00000
A0 alarm and fan temperature di erential 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
AL temperature alarm threshold/deviation 20.0 25.0 20.0 20.0 22.0 15.0 18.0 20.0
AH high temperature alarm threshold/deviation 20.0 25.0 20.0 20.0 22.0 25.0 20.0 25.0
Ad temperature alarm delay 60 70 60 60 20 40 30 25
A4 3rd input con guration - - - - 0410
A7 digital input alarm delay - - - - 0 20 30 20
Ac set point dirty condenser alarm 55.0 50.0 70.0 55.0 55.0 55.0 55.0 55.0
AE dirty condenser alarm di erential temperature 10.0 8.0 10.0 10.0 10.0 10.0 10.0 10.0
Acd dirty condenser alarm delay 60 40 200 60 60 60 60 60
F0 enable evaporator fan control - - - - 1010
F1 evaporator fan control set point - - - - 5.0 5.0 5.0 5.0
F2 stop evaporator fan if compressor o -- - - 1111
F3 evaporator fan status during defrost - - - - 1111
Fd post-dripping time - - - - 3456
Table 5.h
Key:
EZY= normal temperature low temperature
1
no defrost defrost by hot gas
2
defrost by time automatic night-time set point variation from digital input
3
heating output (reverse) digital input alarm management
4
defrost with temp. control (d0= 4) defrost by temperature (d0=4)
