Carel IR32 Series

14. Schemi di collegamento
14.1 IR32 versioni con ingresso NTC
IR32V – NTC: Versione V, alimentazione 110/240 Vac-dc
IR32V – NTC: con alimentazione 12/24 Vac-dc
IR32W – NTC: con alimentazione 12/24 Vac-dc
IR32Z – NTC: con alimentazione 12/24 Vac-dc
14. Wiring diagrams
14.1 IR32 with NTC input
IR32V - NTC: V version, power supply 110/240Vac-dc
IR32V - NTC: power supply 12/24Vac-dc
IR32W - NTC: power supply 12/24Vac-dc
IR32Z - NTC: power supply 12/24Vac-dc
70
OUT 1
POWER
DIG.IN
COM
NTC1 NTC2
c
19 20
1 2 3
6 7 8 9
mod. H 110÷240
_
~
OUT 1
12-24 V
2 VA
DIG.IN
NTC1
NTC2.
POWER
COM
_
~
1 2 3
4 5 6 7 8 9
c
SERIAL
LINK
NTC1
OUT 1
12-24 V
3 VA
POWER
NTC2
OUT 2
DIG.IN
COM
_
~
4 5 6 7 8 9
c
1 2 3
13 14 15
c
SERIAL
LINK
OUT 1
12-24 V
3 VA
OUT 2
OUT 3
OUT 4
POWER
NTC1
NTC2
DIG.IN
COM
4 5 6 7 8 9
1 2 3
10 11 12 13 14 15 16 17 18
~
_
SERIAL
LINK
