24
set point
differential (half of the total)
humidification
dehumidification
HUMIDITY REGOLATION
3. USER GUIDE
The Liquid Crystal Display is the main communicative channel between pCO and
user. All information that can be read on display is stored in a series of masks. All
masks will be listed below.
3.1 MASK
The typical mask structure is the following (the display has 4 rows x 20 columns):
In case of numeric setting fields, press
ENTER
to move the cursor from the current
position (for example 0,0) to the first figure of the first numeric field available; if the
current position corresponds to the last possible setting field, by pressing
ENTER
the cursor will return on "home" position - 0,0.
