Carel pCO1 series Manual

Standard Shelter
Cod. +030221471 – Rel. 2.0 – April 01, 2003
24
DESCRIPTION OF THE PARAMETER SCREEN DEFAULT
VALUE
RANGE UOM
MOP start delay F9 30 0-500 seconds
MOP threshold F9 40.0 -50.0 - 99.9 ºC
MOP threshold integration time F9 40 0-255 seconds
High condensing temp. protection threshold Fa 75.0 0-99.9 ºC
Integration time for high condensing temp. threshold Fa 40 0-255 seconds
High suction temperature threshold Fb 30.0 0-100.0 ºC
Custom Valve: minimum steps Fc 0 0-8100
Custom Valve: maximum steps Fc 1600 0-8100
Custom Valve: closing steps Fd 3600 0-8100
Custom Valve: return steps Fd 0 0-8100
Custom Valve: enable extra step in opening Fe No No-Yes
Custom Valve: enable extra step in closing Fe No No-Yes
Custom Valve: operating current Ff 250 0-1000 mA
Custom Valve: holding current Ff 100 0-1000 mA
Custom Valve: frequency Fg 100 32-330 Hertz
Custom Valve: duty cycle Fg 50 0-100 %
Minimum evaporation pressure probe value Fh -0.5 -9.9-10.0 bar
Maximum evaporation pressure probe value Fh 7.0 3.5-40.0 Bar
Low superheating alarm delay Fi 0 0-3600 seconds
High suction temperature alarm delay Fi 0 0-3600 seconds
LOP alarm delay Fj 0 0-3600 seconds
MOP alarm delay Fj 0 0-3600 seconds
TIMES →
Outlet fan start and stop delay T0 10 / 20 0-999 seconds
Integration time for P+I temperature control T1 600 0-9999 seconds
Travel time for 3 position freecooling damper T1 180 0-9999 seconds
Low pressure alarm delay T2 180 0-9999 seconds
High-low temperature-humidity alarm delays T2 600 0-9999 seconds
Relay 4 activation delay - serious alarm T3 0 0-999 seconds
Relay 5 activation delay - minor 1 T3 0 0-999 seconds
Relay 6 activation delay - minor 2 T3 0 0-999 seconds
Dirty filter alarm delay T4 10 0-9999 seconds
Air flow switch alarm delay T4 10 0-9999 seconds
Minimum compressor off time T5 180 0-9999 seconds
Minimum compressor on time T5 60 0-9999 seconds
Delay between compressor starts T6 360 0-9999 seconds
Minimum delay between starts of different compressors T6 10 0-9999 seconds
Freecooling inactivity time to limit excessive humidity T7 120 0-999 minutes
Activation delay between heaters T8 3 0-999 seconds
INITIALISATION →
Enter password for Reset default value function V0 1234 0-9999
Delete BASIC alarm LOG V1 No No-Yes
Enter new manufacturer password V2 1234 0-9999
