Carel pCO2 Series

S&2ð
cod. Carel +030221826 rel. 2.0 dated 03/10/02
49
 86(57(50,1$/02817,1*
 3DQHOPRXQWLQJ
 3&27
Legend Fig. 7.1.1.1, (dimensions in mm).
Q GHVFULSWLRQ
1 rear cover
2 panel
3 front cover
4 drilling template
(tolerance: -0,5 ÷ +1mm on the indicated dimensions)
5 rear cover gasket
6 front cover gasket
7DE
 3&2,
Legend Fig. 7.1.2.1, (dimensions in mm).
Q GHVFULSWLRQ
1 external frame
2 panel
3 terminal
4 drilling template
(tolerance: ± 0,5mm on the indicated
dimensions)
5 front basket
7DE

:$51,1* the maximum thickness of the
panel is 6mm.
 :DOOPRXQWLQ J
Wall mounting requires the use of a special mounting
racket and a standard 3-module switchbox for the passage
of the cable. With reference to Fig. 7.2.1, fasten the
bracket (1) to the wall (3) using the screws (2); clip the
rear of the instrument onto the bracket.
)LJ
)LJ 
)LJ

