UB 12 - UB 13 - UB 15
Drain Plug
S
C
CONSOLE
SEAT
SC OPTIONS
Please follow these s teps to prepare your boat to navigate:
1) Inflate the tubes (page 7)
2) Placing the drain plug.(thi s page)
PREPARE YOUR BOAT:
the drain plugs are secured into the valves
WARNING :
Before launching the boat,make sure that
STANDARD ACCESORIES
*PADLE *PUMP *REPAIR KIT
Bas ic UB 12B UB 13B UB 15B
Sea t/Console UB 12SC UB 13SC UB 15SC
O.A (A)
3,63 mt
4,00 mt 4,55 mt
LENGTH
12'
13'3'' 15'
O.A (B)
1,67 mt
1,82 mt 1,97 mt
BEAM
5'6''
6' 6'6''
MAX 31 KW 38 KW 52,3 KW
ENGINE 40 HP 50 HP 70 HP
ENGINE
SHAFT
LONG
( 20”)
LONG
( 20”)
LONG
( 20”)
MAX LOAD 723 KG 827 KG 907 KG
CAPACITY 1593 LBS 1823 LBS 2000 LBS
MAX No.
PERSONS 5 6 8
APROX 160 KG 185 KG 205 KG
(B) 352 LBS 407 LBS 451 LBS
APROX 174 KG 200 KG 220 KG
WEIGHT B.
WEIGHT B.(SC) 383 LBS 440 LB
S 484 LBS
APROX GAS 50 LTS 55 LTS 90 LTS
CAPACITY 13 GAL 14 GAL 24 GAL
tube O mt
0,44 0,44 0,49
Fuel fill
Bilge
pump
sender
Fuel line
Fuel tank
DISTRIBUTION UNDER DECK
DISTRIBUTION UNDER DECK
ANCHOR
STORAGEFUEL FILL
STORAGE
SEAT
B
A
15/18
